Automatic corner and side sealing machine

GPE-50+GPH-50

The automatic corner and side sealing machine is aimed at the electronics industry and the industry that needs sea transportation. The equipment is sealed with dust, moisture, oxidation and acidity. It can be combined with the GPA/GPB/GPC model to form an I-shaped sealing machine. This type of sealing machine is widely used in food, medicine, toys, tobacco, daily chemicals, electronics and other domestic and foreign industries.

Max Speed

20m/min

Packing Size

Max
L∞×W500×H500mm

Min
L150×W150×H140mm

FEATURES

SPECIFICATIONS

MODEL GPE-50 GPH-50
Packing speed 20m/min 300-360Pcs/h
Max. Packing size L∞×W500×H500mm L500×W500×H500mm
Min. Packing size L150×W150×H140mm L320×W200×H180mm
Power supply 220/380V, 1ф -3ф, 50/60Hz 220/380V, 1ф -3ф, 50/60Hz
Power 240W 6kg/ cm³ 150NL/min
Adhesive tape width 48mm, 60mm, 75mm 48mm, 60mm, 75mm
Machine dimension L1170×W900×H1350 L2100×W1200×H1580mm
Machine weight 170kg 450kg

PACKAGE EFFECT
